Cardboard Box Shredder Specification

Material
Mild Steel/Steel

Size
Approx. 1500 mm x 900 mm x 1200 mm

Noise Level
Below 70 dB

Frequency
50/60 Hz

Color
White & Black

Automatic Grade
Automatic

Sheet Capacity
1-3 layers of cardboard at a time

Capacity
60-120 kg/hr

Processing Type
Shredding and Fodder Cutting

Thickness
Up to 20 mm cardboard thickness

Voltage
220V/380V/415V (as per requirement)

Application
Cardboard Box Shredding for Packaging Material/Recycling

Control System
Panel based electronic control

Motor Power
3 HP to 10 HP (depending on model)

Weight
Approx. 400-900 kg depending on model

Cutter Type
High Hardened Alloy Steel Blades

Maintenance
Low, Easy Access for Blade Change

Mobility
Fixed or Wheel-Mounted (optional)

Input Size
Accepts up to 700 mm width cardboard

Production Use
Warehouse, Packaging, Printing Industry, Recycling Centers

Operating Temperature
5C - 45C

Discharge Type
Bottom Ejection or Collection Tray

Shred Width
2 mm to 12 mm strips or mesh (adjustable)

Suitable Materials
Corrugated Cardboard, Carton Boxes, Kraft Paper Sheets

Safety Feature
Overload Protection, Emergency Stop Button

Feeding Type
Manual or Conveyor Feed (optional)

Power Consumption
Approx. 2.5-7 kW

Lubrication
Manual/Automatic (optional)

Cardboard Box Shredder Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Month

Delivery Time
30 Days

About Cardboard Box Shredder

Product Details:

Minimum Order Quantity	1 Piece
Shredding Machine Type	Single Shaft
Capacity	200 kg/hr
Shredding Material	Cardboard, Carton Box, Corrugated Box
Brand	Maxin India
Automation Grade	Automatic
Speed	30 RPM
Voltage	240 V
Finishing	Color Coated
Country of Origin	Made in India
Frequency	50 Hz

We are engaged in offering Cardboard Box Shredder to our clients. Our range of all products is widely appreciated by our clients.

Additional Information:

Item Code: Hodis-750
Production Capacity: 2 ton per hr.
Delivery Time: 30 days

High Efficiency and Flexibility

With its adjustable shred width (2-12 mm) and capability to process up to 3 layers of corrugated cardboard, carton boxes, or kraft paper, this shredder provides tailored output for various recycling and packaging needs. Its design suits both entry-level and larger industrial operations, supporting continuous operation at 60-120 kg/hr and easy adjustment for different input materials.

Enhanced Safety and Simple Maintenance

Built-in safety features, including overload protection and an emergency stop button, ensure operator security during use. Maintenance is simplified by easy blade access, while optional lubricating systems-manual or automatic-prolong the lifespan of critical components. The overall design minimizes downtime and reduces the effort needed for routine servicing.

Versatile Applications for Modern Industries

This shredder caters to the warehousing, packaging, printing, and recycling sectors across India. Suitable for distributors, manufacturers, and service providers, it turns waste cardboard into valuable packaging or recycling fodder, contributing both to operational efficiency and sustainability objectives. Mobility options and a range of voltage compatibility further enhance its adaptability.

FAQ's of Cardboard Box Shredder:

Q: How does the Cardboard Box Shredder operate and what is its maximum input size?

A: The machine operates via a panel-based electronic control system and can be fed manually or with an optional conveyor. It accepts cardboard sheets or boxes up to 700 mm in width and handles 1-3 layers at a time, making it ideal for processing large quantities efficiently.

Q: What materials are suitable for shredding with this device?

A: This shredder efficiently processes corrugated cardboard, carton boxes, and kraft paper sheets up to 20 mm thick, turning them into strips or mesh suitable for packaging or recycling purposes.

Q: What safety features are included in the shredder design?

A: Operator safety is ensured through integrated overload protection and an emergency stop button. These features are designed to prevent accidents and damage, offering peace of mind during continuous industrial use.

Q: What are the discharge and mobility options available?

A: Discharge options include bottom ejection or a collection tray for easy material handling. For convenience, the shredder is available as a fixed or optional wheel-mounted unit, allowing users to position it as suited to their workflow.

Q: How easy is the maintenance process for the Cardboard Box Shredder?

A: Maintenance is low and straightforward, thanks to easy access for blade changes and optional manual or automatic lubrication systems. Routine upkeep can be performed quickly to keep downtime minimal and extend the machine's service life.

Q: Where is this shredder best utilized, and who can benefit from it?

A: This shredder is ideal for warehouses, packaging units, printing houses, and recycling centers. Distributors, exporters, manufacturers, suppliers, and service providers in the packaging and recycling sectors across India will find it immensely beneficial for efficient waste processing and resource recovery.
